# CLI Network Troubleshooting Utilities ThousandEyes provides a full suite of terminal based Network, DNS, and Voice utilities. These utilities come from the same code base that our Agents use to perform tests, and provide enhanced insight during troubleshooting. ## Installing CLI Network Troubleshooting Utilities The ThousandEyes Utilites Suite is provided by the `te-agent-utils` package and is available for any host running a [supported Linux distribution](https://docs.thousandeyes.com/product-documentation/global-vantage-points/enterprise-agents/installing/supported-enterprise-agent-operating-systems). ThousandEyes repositories are automatically added to a host's package manager during Enterprise Agent installation. Hosts without an Enterprise Agent will require manual installation of a ThousandEyes software package repository. ### Installation for Ubuntu #### Install the ThousandEyes APT Repository Add the ThousandEyes repository ``` sudo apt-add-repository https://apt.thousandeyes.com ``` Add the ThousandEyes signing key ``` sudo wget -q https://apt.thousandeyes.com/thousandeyes-apt-key.pub -O- | sudo apt-key add - ``` Changes will be applied during the update process ``` sudo apt-get update ``` If the key has been properly added it will be listed as a trusted key ``` sudo apt-key list ... /etc/apt/trusted.gpg.d/thousandeyes-apt-key.pub.gpg --------------------------------------------------- pub rsa2048 2012-08-13 [SC] AA5F BA03 CE4E F309 B7E3 D4E1 C99A 15F5 BE71 8900 uid [ unknown] ThousandEyes ... ``` #### Install the te-agent-utils Software Package ``` sudo apt-get install te-agent-utils ``` ### Installation for YUM (RedHat, Rocky, Amazon, CentOS, and Oracle Linux) #### Install the ThousandEyes YUM Repository Add the applicable ThousandEyes repository ``` sudo yum-config-manager --add-repo https://yum.thousandeyes.com/RHEL/9/x86_64 # RHEL, Rocky, and Oracle 9 sudo yum-config-manager --add-repo https://yum.thousandeyes.com/CentOS/8/x86_64 # CentOS 8 sudo yum-config-manager --add-repo https://yum.thousandeyes.com/Amazon/2/x86_64 # Amazon Linux 2 ``` Add the ThousandEyes signing key ``` sudo wget --directory-prefix /etc/pki/rpm-gpg/ https://yum.thousandeyes.com/RPM-GPG-KEY-thousandeyes ``` Changes will be applied during the update process ``` sudo yum update ``` Check the GPG key ``` sudo gpg --show-keys --with-fingerprint /etc/pki/rpm-gpg/RPM-GPG-KEY-thousandeyes ``` The ThousandEyes key fingerprint should be as follows ``` pub rsa2048 2012-08-13 [SC] AA5F BA03 CE4E F309 B7E3 D4E1 C99A 15F5 BE71 8900 uid ThousandEyes ``` #### Install the te-agent-utils Software Package ``` sudo yum install te-agent-utils ``` ## Network Utilities ### te-ping A replacement for traditional ping, and can be run in a number of different application protocol modes. te-ping includes options to run in SACK, SYN, ICMP and VoIP modes, designed for use with different types of targets, and is consistent with the way that ThousandEyes measures end-to-end metrics in Network tests. Outputs include Loss, Latency and Jitter. Requires sudo permissions. #### Syntax and Options (sudo) te-ping \[options] \ | **Parameter** | **Description** | | ------------- | --------------------------------------------- | | target-ip | IP address or DNS name of the target machine. | | **Option (short)** | **Option (long)** | **Description** | **Default Value** | | ------------------ | ----------------- | --------------------------------------------------------------------------------------------------------- | ----------------- | | -h | --help | displays usage instructions | n/a | | | --source-port | source port to be used for the test, do not use in icmp mode | \ | | -p | --port | destination port for the probe, do not use in icmp mode | 80 | | -c | --count | number of packets to be sent by the test | 50 | | -I | --interval | initial maximum interval between packets (in ms) | 40 | | -i | --interface | interface name to use for the test (use in conjunction with --source-ip option) | any | | -s | --source-ip | source IP address (use in conjunction with the --interface option) | n/a | | -M | --mode | transmission mode for the test; accepts **sack**, **syn**, **icmp, rtp** (UDP+RTP)**, or sip** options | sack | | -v | --verbose | verbosity of the test; short command accepts -v (verbose) or -vv (very verbose), -vvv (very very verbose) | n/a | #### Example ``` $ sudo te-ping -i eth0 74.125.225.176 ``` ``` --- 74.125.225.176 ping statistics --- 50 packets transmitted, 50 received, 0.0% packet loss rtt min/avg/max/mdev = 68.00/69.42/71.00/0.58 ms ``` ``` $ sudo te-ping -c 25 thousandeyes.com ``` ``` --- 54.215.17.122 ping statistics --- 25 packets transmitted, 25 received, 0.0% packet loss rtt min/avg/max/mdev = 5.00/5.68/6.00/0.44 ms ``` ### te-pathtrace Runs a traceroute, using the same methods as are used by ThousandEyes to the endpoint. In addition to obtaining the IP addresses transited by each probe, our code shows quoted-ttl, response-ttl and MPLS label values for each probe. Since each agent test runs 3 probes (test attempts) to the target, if you want consistent results with that of the agent, run with option -P 3, to obtain three sets of trace data. Requires sudo permissions. Note in the example shown that the path to the same target IP diverges in two separate trace requests from the same target, at hop # 4 (shown in bold for emphasis). Using the Paris-traceroute algorithm (which is used by ThousandEyes in our Path Visualization view), this would show a path split, as in the image shown below. ![](https://1112912342-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2F-M4QARF6s57qxMrOHDTZ%2Fuploads%2Fgit-blob-08df937959165947ae13e0e86424becf8c12366c%2Fproduct-documentation_advanced-troubleshooting_cli-network-troubleshooting-utilities-1.png?alt=media\&token=421f459b-0a6b-4499-a513-f4860e559c70) #### Syntax and Options (sudo) te-pathtrace \[options] \ | **Parameter** | **Description** | | ------------- | --------------------------------------------- | | target-ip | IP address or DNS name of the target machine. | | **Option (short)** | **Option (long)** | **Description** | **Default Value** | | ------------------ | ----------------- | ------------------------------------------------------------------------------------ | ----------------- | | -h | --help | displays usage instructions | n/a | | | --source-port | source port to be used for the test, do not use in icmp mode | \ | | -p | --port | destination port for the probe, do not use in icmp mode | 80 | | -w | --wait-time | how long to wait for each probe reply (in ms) | 1000 | | -g | --gap-limit | maximum number of consecutive unresponsive hops before stopping | 6 | | -l | --max-loops | number of times the same IP can be encountered before stopping | 2 | | -P | --paths | number of parallel paths to trace | 1 | | -M | --mode | transmission mode to use for the test; accepts **tcp, sack, icmp, rtp,** or **sip.** | tcp | | -v | --verbose | verbosity level, accepts -v (verbose), -vv (very verbose), -vvv (very very verbose) | n/a | #### Example ``` $ sudo te-pathtrace -P 2 74.125.225.176 ``` ``` Tracing 2 paths from 192.168.1.209 to 74.125.224.176:80... 1 192.168.1.1 (0 ms), q-ttl=1, icmp=(11-0), r-ttl=64 2 71.119.37.1 (19 ms), q-ttl=1, icmp=(11-0), r-ttl=126 3 130.81.195.70 (26 ms), q-ttl=1, icmp=(11-0), r-ttl=253 4 130.81.29.126 (22 ms), q-ttl=1, icmp=(11-0), r-ttl=252 5 140.222.227.21 (26 ms), q-ttl=1, icmp=(11-0), r-ttl=251 6 152.63.114.229 (27 ms), q-ttl=1, icmp=(11-0), r-ttl=250 7 * 8 216.239.46.40 (59 ms), q-ttl=1, icmp=(11-0), r-ttl=249 t 9 64.233.174.186 (58 ms), q-ttl=1, icmp=(11-0), r-ttl=249 10 216.239.46.154 (72 ms), q-ttl=1, icmp=(11-0), r-ttl=245 11 216.239.46.147 (89 ms), q-ttl=1, icmp=(11-0), r-ttl=245 12 209.85.251.9 (71 ms), q-ttl=1, icmp=(11-0), r-ttl=245 13 74.125.225.176 (70 ms), q-ttl=0, icmp=(0-0), r-ttl=53 1 192.168.1.1 (0 ms), q-ttl=1, icmp=(11-0), r-ttl=64 2 71.119.37.1 (20 ms), q-ttl=1, icmp=(11-0), r-ttl=126 3 130.81.195.70 (22 ms), q-ttl=1, icmp=(11-0), r-ttl=253 4 130.81.199.40 (22 ms), q-ttl=1, icmp=(11-0), r-ttl=252 5 140.222.227.21 (25 ms), q-ttl=1, icmp=(11-0), r-ttl=251 6 152.63.115.246 (25 ms), q-ttl=1, icmp=(11-0), r-ttl=250 7 * 8 64.233.174.238 (24 ms), q-ttl=1, icmp=(11-0), r-ttl=249 9 64.233.174.192 (41 ms), q-ttl=1, icmp=(11-0), r-ttl=249 10 216.239.46.152 (73 ms), q-ttl=1, icmp=(11-0), r-ttl=245 11 216.239.46.145 (73 ms), q-ttl=1, icmp=(11-0), r-ttl=245 12 209.85.251.9 (71 ms), q-ttl=1, icmp=(11-0), r-ttl=245 13 74.125.225.176 (70 ms), q-ttl=0, icmp=(0-0), r-ttl=53 ``` ### te-pathmtu Designed to quickly interrogate the path between your test endpoint and the target. The command will find the smallest allowed MTU on the path between the endpoints, allowing inference of certain types of tunnels, or misconfigurations of MTU size on routers between the endpoints. By default, the MTU is 1500 bytes. #### Syntax and Options (sudo) te-pathmtu \[options] \ | **Parameter** | **Description** | | ------------- | --------------------------------------------------------------- | | target-ip | IP address of the target machine or DNS name of target machine. | | **Option (short)** | **Option (long)** | **Description** | **Default Value** | | ------------------ | ----------------- | ----------------------------------------------------------------------------------- | ----------------- | | -h | --help | displays usage instructions | n/a | | | --source-port | source port to be used for the test, do not use in icmp mode | \ | | -p | --port | destination port for the probe, do not use in icmp mode | 80 | | -w | --wait-time | how long to wait for each probe reply (in ms) | 1000 | | -m | --max-mtu | the maximum possible transmission unit of the output interface (in bytes) | 1500 | | -P | --paths | number of parallel paths to trace | 1 | | -i | --interface | network interface to use for this test (use in conjunction with --source-ip option) | any | | -s | --source-ip | source IP address ( use in conjunction with --interface option) | n/a | | -M | --mode | transmission mode to use for the test; accepts **tcp, icmp, rtp,** or **sip** | tcp | | -v | --verbose | verbosity level, accepts -v (verbose), -vv (very verbose) -vvv (very very verbose) | n/a | #### Example ``` $ sudo te-pathmtu -i eth0 98.139.183.24 ``` ``` Looking up path MTU from 89.187.112.188 to 98.139.183.24:80 Path MTU: 1500 ``` ### te-bw Designed as a replacement for iPerf, te-bw allows measurement of bandwidth, while having control of a single endpoint, and without the need to have exclusive access to the pipe. Use te-bw to measure estimated capacity, and available bandwidth on the pipe between the endpoint and target. Requires sudo permissions. When measuring bandwidth, te-bw shows the limiting bandwidth for UPSTREAM communication from the endpoint (ability of the endpoint to send data to the target), and DOWNSTREAM bandwidth from the target (ability for the target to send data to the endpoint). This is an important point for servers behind asymmetric links, such as ADSL. #### Syntax and Options (sudo) te-bw \[options] \ | **Parameter** | **Description** | | ------------- | --------------------------------------------- | | target-ip | IP address or DNS name of the target machine. | | **Option (short)** | **Option (long)** | **Description** | **Default Value** | | ------------------ | ----------------- | ------------------------------------------------------------------------------------------------ | ----------------------------------------------------------------------------------------- | | -h | --help | displays usage instructions | n/a | | -p | --port | destination port on the target. Do not use in icmp mode | \ | | -j | --jitter | mean deviation of the round trip time (in μs) | if not specified, will be calculated by running an initial ping against the target | | -z | --probe-size | maximum size of the probe packets (in bytes) | 1440 | | -c | --capacity | capacity of the link (in Mbps), 0=unlimited. | if not specified, will be calculated by running an initial calculation against the target | | -s | --source-ip | source IP address ( use in conjunction with --interface option) | n/a | | -T | --timeout | timeout for the test to complete (in secs) , 0 = unlimited | 10 | | -v | --verbose | verbosity level, short option accepts -v (verbose), -vv (very verbose), -vvv (very very verbose) | n/a | | -i | --interface | network interface to use for the test (use in conjunction with --source-ip option) | any | | -M | --mode | transmission mode to use for the test; accepts **icmp** or **tcp** | tcp | #### Example ``` $ sudo te-bw -i eth0 192.168.1.209 74.125.225.176 ``` ``` Running ping task to estimate jitter 80 bytes from 74.125.225.176: tcp_req=1 ttl=52 time=115 ms 80 bytes from 74.125.225.176: tcp_req=2 ttl=52 time=115 ms 80 bytes from 74.125.225.176: tcp_req=3 ttl=52 time=115 ms 80 bytes from 74.125.225.176: tcp_req=4 ttl=52 time=115 ms 80 bytes from 74.125.225.176: tcp_req=5 ttl=52 time=115 ms 80 bytes from 74.125.225.176: tcp_req=6 ttl=52 time=115 ms 80 bytes from 74.125.225.176: tcp_req=7 ttl=52 time=115 ms 80 bytes from 74.125.225.176: tcp_req=8 ttl=52 time=115 ms 80 bytes from 74.125.225.176: tcp_req=9 ttl=52 time=115 ms 80 bytes from 74.125.225.176: tcp_req=10 ttl=52 time=115 ms --- 74.125.225.176 ping statistics --- 10 packets transmitted, 10 received, 0.0% packet loss rtt min/avg/max/mdev = 115.00/115.00/115.00/0.00 ms Capacity ======================================== Estimated rate: 96.1 Mbps +/-0 Data sent: 8.80 KB Probe size: 1420 B Wall time: 3.59 secs PCap stats: 200/0 pkts Return code: 0 () ======================================== Available bandwidth ======================================== Estimated rate: 78.0 Mbps +/-8 Data sent: 50.60 KB Probe size: 1420 B Wall time: 4.34 secs PCap stats: 1150/0 pkts Return code: 0 () ======================================== ``` ### te-oneway te-oneway performs an Agent-to-Agent test in a single direction. #### Syntax and Options (sudo) te-oneway \[options] \ | **Parameter** | **Description** | | ------------- | ------------------------------------------- | | target-ip | IP address or DNS name of the target agent. | | **Option (short)** | **Option (long)** | **Description** | **Default Value** | | ------------------ | ----------------------- | ------------------------------------------------------------------------------------------------ | ----------------- | | -h | --help | displays usage instructions | | | -v | --verbose | verbosity level, short option accepts -v (verbose), -vv (very verbose), -vvv (very very verbose) | | | | --stunner-host | host in which to reach the STUNNER server | | | | --stunner-port | port in which to reach the STUNNER server | | | -p | --port | destination probe port on the target agent | 5000 | | -i | --interface | network interface to use for the test (use in conjunction with --source-ip option) | any | | -s | --source-ip | source IP address (use in conjunction with --interface option) | any | | | --dscp arg | DSCP value (decimal), 0=best effort | 0 | | | --payload-size | payload size to use | 56 | | -M | --mode | mode: tcp or udp | tcp | | -b | --behind-nat | behave as if this client is behind a NAT (makes sense when using STUNNER) | | | | --agent-id | the agent id to use when connecting and authenticating to the STUNNER | | | | --agent-token | the agent token to use when connecting and authenticating to the STUNNER | | | | --packet-rate | Rate at which to send packets (in pps), or 0 for RTT-based mechanism | 0 | | -a | --asymmetric-interfaces | Support separate ingress/egress interfaces | | ### te-stresstest te-stresstest runs a suite of tests in parallel against a single endpoint. The goal is to simulate multiple agents running tests against one endpoint. #### Syntax and Options (sudo) te-stresstest \[options] \ | **Parameter** | **Description** | | ------------- | --------------------------------------------- | | target-ip | IP address or DNS name of the target machine. | | **Option (short)** | **Option (long)** | **Description** | **Default Value** | | ------------------ | ----------------- | ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- | ----------------- | | -h | --help | produce this help message | | | -p | --port | the destination probe port (in TCP mode) | 80 | | | --ping | number of concurrent ping tasks | 0 | | | --pathtrace | number of concurrent pathtrace tasks | 0 | | | --pathmtu | number of concurrent pathmtu tasks | 0 | | | --bw | number of concurrent available bandwidth tasks (runs capacity estimation too if --capacity is not specified) | 0 | | | --voice | number of concurrent voice tasks | 0 | | -M | --mode | mode: tcp, icmp, or rtp | tcp | | -g | --gap-limit | number of unresponsive hops before stopping ('auto' to perform distance estimation to destination, in which case it autouses 20 estimated\_distance or 7 if destination doesn't reply) | auto | | -j | --jitter | mean dev of two-way jitter (in usecs) | | | -z | --probe-size | maximum size of probe packets (in bytes) | 1440 | | -c | --capacity | capacity of the link (in Mbps, 0=unlimited) | 0 | | | --dscp | DSCP value (decimal), 0=best effort | 0 | | | --codec | audio codec, 0=G711, 1=G722\_24, 2=G722\_32, 3=G726, 4=G723, 5=G729a | 0 | | -o | --clock-offset | clock offset with server (in secs) | 0 | | -t | --threads | # of threads | 1 | | | --voice-threads | runs voice tasks in a dedicated probe task executor (boost asio queue) with n threads (0 means that voice tasks run in shared probe task executor; (more than 0 means that voice tasks run in a dedicated probe task executor with that many threads) | 0 | | -d | --duration | duration of the test (in secs, 0=unlimited) | 10 | | -T | --timeout | deadline for individual tasks to complete (in ms) | 5 | | -i | --interface | interface (use in conjunction with --source-ip option) | | | -s | --source-ip | source IP address (use in conjunction with --interface option) | | | -v | --verbose | verbosity level: -v, -vv, or -vvv | | ### te-tput-tcp te-tput-tcp runs a throughput test to an Enterprise Agent. The test will send as much data as it can in the set amount of time to measure the maximum data throughput to an agent. #### Syntax and Options (sudo) te-tput-tcp \[options] \ | **Parameter** | **Description** | | ------------- | --------------------------------------------- | | target-ip | IP address or DNS name of the target machine. | | **Option (short)** | **Option (long)** | **Description** | **Default Value** | | ------------------ | ----------------------- | --------------------------------------------------------------------- | ----------------- | | -h | --help | produce this help message | | | -v | --verbose | verbosity level: -v, -vv, or -vvv | | | | --source-port | the source probe port, 0=random | 0 | | -p | --port | the destination probe port | 5000 | | -i | --interface | interface (use in conjunction with --source-ip option) | | | -s | --source-ip | source IP address (use in conjunction with --interface option) | | | | --dscp | DSCP value (decimal), 0=best effort | 0 | | | --agent-id | the agent id to use when connecting and authenticating to the STUNNER | 0 | | | --mss | mss to use | 1460 | | | --send-buffer | send buffer size to use | 0 | | | --no-delay | use no delay on socket (Nagle) | 0 | | | --congestion-algo | the TCP congestion algorthm to use for setsockopt TCP\_CONGESTION | | | -d | --stream-duration | stream duration (in secs) | 5 | | -a | --asymmetric-interfaces | Support separate ingress/egress interfaces | | ### te-tput-udp te-tput-udp runs a throughput test to an Enterprise Agent, similar to te-tput-tcp but using UDP rather than TCP. #### Syntax and Options (sudo) te-tput-udp \[options] \ | **Parameter** | **Description** | | ------------- | --------------------------------------------- | | target-ip | IP address or DNS name of the target machine. | | **Option (short)** | **Option (long)** | **Description** | **Default Value** | | ------------------ | ----------------------- | --------------------------------------------------------------------- | ----------------- | | -h | --help | produce this help message | | | -v | --verbose | verbosity level: -v, -vv, or -vvv | | | | --source-port | the source probe port, 0=random | 0 | | -p | --port | the destination probe port | 5000 | | -i | --interface | interface (use in conjunction with --source-ip option) | | | -s | --source-ip | source IP address (use in conjunction with --interface option) | | | | --dscp | DSCP value (decimal), 0=best effort | 0 | | | --agent-id | the agent id to use when connecting and authenticating to the STUNNER | 0 | | | --payload-size | paylod size to use | 1400 | | -d | --stream-duration | stream duration (in secs) | 5 | | -r | --rate | rate in kbps | 10240 | | -a | --asymmetric-interfaces | Support separate ingress/egress interfaces | | ## DNS Utilities ### te-dns-trace A special version of dig +trace which follows CNAME records across zones, in order to get to the requested record type. This is the same logic as is followed using the DNS Domain Trace test inside ThousandEyes. In addition, you'll receive more verbose feedback when the trace attempt is unsuccessful at retrieving records from an authoritative server, before the request fails over to a subsequent server. In the example shown below for [www.healthcare.gov](http://www.healthcare.gov) A, notice how the trace is followed from CNAME retrieved from the .gov zone, to Akamai, where the ultimate A record resides. A standard dig +trace request would stop at the line shown in bold. Does not require sudo permissions. #### Syntax and Options (sudo) te-dns-trace \ \[type] | **Parameter** | **Description** | **Required?** | **Default Value** | | ------------- | ---------------------- | ------------- | ----------------- | | domain | domain name to look up | Y | n/a | | type | DNS record type | N | A | #### Example ``` $ sudo te-dns-trace www.healthcare.gov A ``` ``` gov. 172800 IN NS b.gov-servers.net. gov. 172800 IN NS a.gov-servers.net. ;; Received 143 bytes from 198.41.0.4(a.root-servers.net.) in 25 ms healthcare.gov. 86400 IN NS eur5.akam.net. healthcare.gov. 86400 IN NS usc3.akam.net. healthcare.gov. 86400 IN NS use2.akam.net. healthcare.gov. 86400 IN NS use4.akam.net. healthcare.gov. 86400 IN NS usw2.akam.net. healthcare.gov. 86400 IN NS asia1.akam.net. healthcare.gov. 86400 IN NS ns1-78.akam.net. healthcare.gov. 86400 IN NS ns1-252.akam.net. ;; Received 202 bytes from 209.112.123.30(b.gov-servers.net.) in 23 ms www.healthcare.gov. 120 IN CNAME www.geodirector.hc.gov.akadns.net. ;; Received 83 bytes from 23.74.25.64(eur5.akam.net.) in 72 ms net. 172800 IN NS m.gtld-servers.net. net. 172800 IN NS l.gtld-servers.net. net. 172800 IN NS k.gtld-servers.net. net. 172800 IN NS j.gtld-servers.net. net. 172800 IN NS i.gtld-servers.net. net. 172800 IN NS h.gtld-servers.net. net. 172800 IN NS g.gtld-servers.net. net. 172800 IN NS f.gtld-servers.net. net. 172800 IN NS e.gtld-servers.net. net. 172800 IN NS d.gtld-servers.net. net. 172800 IN NS c.gtld-servers.net. net. 172800 IN NS b.gtld-servers.net. net. 172800 IN NS a.gtld-servers.net. ;; Received 508 bytes from 198.41.0.4(a.root-servers.net.) in 27 ms akadns.net. 172800 IN NS ns1-129.akadns.net. akadns.net. 172800 IN NS ns2-129.akadns.net. akadns.net. 172800 IN NS ns17-133.akadns.org. akadns.net. 172800 IN NS a3-129.akadns.net. akadns.net. 172800 IN NS a11-129.akadns.net. akadns.net. 172800 IN NS a9-128.akadns.net. akadns.net. 172800 IN NS a5-130.akadns.org. akadns.net. 172800 IN NS a4-131.akadns.org. akadns.net. 172800 IN NS a10-128.akadns.org. akadns.net. 172800 IN NS a28-129.akadns.org. ;; Received 358 bytes from 192.55.83.30(m.gtld-servers.net.) in 80 ms www.geodirector.hc.gov.akadns.net. 120 IN CNAME production.healthcare.gov.edgekey.net. ;; Received 99 bytes from 193.108.88.129(ns1-129.akadns.net.) in 72 ms edgekey.net. 172800 IN NS ns1-66.akam.net. edgekey.net. 172800 IN NS usw6.akam.net. edgekey.net. 172800 IN NS use9.akam.net. edgekey.net. 172800 IN NS adns1.akam.net. edgekey.net. 172800 IN NS adns2.akam.net. edgekey.net. 172800 IN NS adns3.akam.net. edgekey.net. 172800 IN NS adns4.akam.net. edgekey.net. 172800 IN NS ns4-66.akam.net. edgekey.net. 172800 IN NS ns4-67.akam.net. edgekey.net. 172800 IN NS ns7-65.akam.net. edgekey.net. 172800 IN NS ns7-66.akam.net. edgekey.net. 172800 IN NS ns5-66.akam.net. edgekey.net. 172800 IN NS ns5-64.akam.net. ;; Received 497 bytes from 192.55.83.30(m.gtld-servers.net.) in 81 ms production.healthcare.gov.edgekey.net. 21600 IN CNAME e8132.dscb.akamaiedge.net. ;; Received 91 bytes from 193.108.91.66(ns1-66.akam.net.) in 23 ms akamaiedge.net. 172800 IN NS la1.akamaiedge.net. akamaiedge.net. 172800 IN NS la6.akamaiedge.net. akamaiedge.net. 172800 IN NS la7.akamaiedge.net. akamaiedge.net. 172800 IN NS la3.akamaiedge.net. akamaiedge.net. 172800 IN NS lar6.akamaiedge.net. akamaiedge.net. 172800 IN NS lar2.akamaiedge.net. akamaiedge.net. 172800 IN NS ns3-194.akamaiedge.net. akamaiedge.net. 172800 IN NS ns2-194.akamaiedge.net. akamaiedge.net. 172800 IN NS ns4-194.akamaiedge.net. akamaiedge.net. 172800 IN NS ns6-194.akamaiedge.net. akamaiedge.net. 172800 IN NS ns7-194.akamaiedge.net. akamaiedge.net. 172800 IN NS ns5-194.akamaiedge.net. akamaiedge.net. 172800 IN NS ns1-1.akamaiedge.net. ;; Received 497 bytes from 192.55.83.30(m.gtld-servers.net.) in 80 ms dscb.akamaiedge.net. 21600 IN NS n3dscb.akamaiedge.net. dscb.akamaiedge.net. 43200 IN NS n2dscb.akamaiedge.net. dscb.akamaiedge.net. 32400 IN NS n4dscb.akamaiedge.net. dscb.akamaiedge.net. 32400 IN NS n7dscb.akamaiedge.net. dscb.akamaiedge.net. 32400 IN NS n1dscb.akamaiedge.net. dscb.akamaiedge.net. 21600 IN NS n6dscb.akamaiedge.net. dscb.akamaiedge.net. 43200 IN NS n5dscb.akamaiedge.net. dscb.akamaiedge.net. 21600 IN NS n0dscb.akamaiedge.net. ;; Received 339 bytes from 184.26.161.192(la1.akamaiedge.net.) in 23 ms e8132.dscb.akamaiedge.net. 20 IN A 23.43.186.194 ;; Received 59 bytes from 63.217.8.179(n3dscb.akamaiedge.net.) in 40 ms ``` ### te-sigchase Provides DNSSEC keychain validation (using bottom-up method) for the target record type. Requires that DNSSEC extensions are supported by routers used by the endpoint. See for a list of devices which do not currently support required extensions for DNSSEC compatibility. Outputs of DNSSEC keychain validation will be the Data Chain, and Trust Tree responses for the validation request, similar to that which is shown in the output of DNSSEC tests in ThousandEyes. Does not require sudo permissions. #### Syntax and Options (sudo) te-sigchase \ \[type] \[key-file] | **Parameter** | **Description** | **Required?** | **Default Value** | | ------------- | ------------------------------------------------------ | ------------- | ---------------------------------------------------------------------------------------------------------------------------------------------------------- | | domain | domain name to validate | Y | n/a | | type | record type to validate | N | A | | key-file | key file used for validation of root server signatures | N | A key file is provided and maintained with the te-agent-utils package. To view the content of the file, look at /var/lib/te-agent-utils/dns-rootserver.key | #### Example ``` $ sudo te-sigchase www.fbi.gov A ``` ``` Data chain: ;; rcode: NOERROR ;; qtype: DNSKEY rrset: . 172800 IN DNSKEY 256 3 8 AwEAAb8sU6pbYMWRbkRnEuEZw9NSir707TkOcF+UL1XiK4NDJOvXRyX195Am5dQ7bRnnuySZ3daf37vvjUUhuIWUAQ4stht8nJfYxVQXDYjSpGH5I6Hf/0CZEoNP6cNvrQ7AFmKkmv00xWExKQjbvnRPI4bqpMwtHVzn6WybBZ6kuqED ;{id = 33655 (zsk), size = 1024b} . 172800 IN DNSKEY 257 3 8 AwEAAagAIKlVZrpC6Ia7gEzahOR+9W29euxhJhVVLOyQbSEW0O8gcCjFFVQUTf6v58fLjwBd0YI0EzrAcQqBGCzh/RStIoO8g0NfnfL2MTJRkxoXbfDaUeVPQuYEhg37NZWAJQ9VnMVDxP/VHL496M/QZxkjf5/Efucp2gaDX6RS6CXpoY68LsvPVjR0ZSwzz1apAzvN9dlzEheX7ICJBBtuA6G3LQpzW5hOA2hzCTMjJPJ8LbqF6dsV6DoBQzgul0sGIcGOYl7OyQdXfZ57relSQageu+ipAdTTJ25AsRTAoub8ONGcLmqrAmRLKBP1dfwhYB4N7knNnulqQxA+Uk1ihz0= ;{id = 19036 (ksk), size = 2048b} sigs: . 172800 IN RRSIG DNSKEY 8 0 172800 20140125235959 20140111000000 19036 . StojN0w3tpyJ6VR+ShcnuekubPXIS/8PHHtp6zJ1mEC/EyUNmGiIN9sEt4jl2yV72saerP6dHXrROceXHFDaGoIN2ge9wdOmzOuKu3zjlvgeUNVcLuzmJFIcPGOkX0vms1dLhEjElM1bBbXRGA8hLAOjbH/sccRSRabLiwpWBT42Gq9o4a1wU6pJhNkQc9nW60zyzLa1PCC+QFRIG53ENBFL1fub8cNjpzBH40RVLmynb4PgzulodAtRM1Rs6z7X8esfOP2dsVE+8ZkY2KzFS6cz5Xw/GkQ3vdiIOJt/QYJ5ZhytkEjPUOV8w01B5mU49qGzMkjW6solFzI3OSde4Q== --- ;; rcode: NOERROR ;; qtype: DS rrset: gov. 86400 IN DS 7698 8 2 6bc949e638442ead0bdaf0935763c8d003760384ff15ebbd5ce86bb5559561f0 gov. 86400 IN DS 7698 8 1 6f109b46a80cea9613dc86d5a3e065520505aafe sigs: gov. 86400 IN RRSIG DS 8 1 86400 20140127000000 20140119230000 33655 . GiRstE42TXAFs/76q+l+ED4WlrqWFS/qJWIzwQbSst5OpCsDuO2SMkJKuu8vWikYwVNrNdGJ4Jody1oYQWMKfXpirAqOVWOb3gpmoUgGn4O/c09xh1fRHx4TZ1gvg2rhit0UFiqrwPf5+aidXhU4O73ZY0A6o7IV1c6DCRPwlqo= --- ;; rcode: NOERROR ;; qtype: DNSKEY rrset: gov. 3600 IN DNSKEY 257 3 8 AQO8daaz7B+yshOfL60rytKd9aOSujgponEw3fwBMEC3/+e9XzHw2k+VKnbJTZ+QaVtpfUd1q9HKZIv/ck83Gl5TjYKE5jtUZ2kpEDZfVNGv6yx0smtWAXv1nCJS9ohnyOTd397eMojGDHqkEC+uojEScZheEkMxzgCZwDAs+/CSU7mSuHtCRZn19xlZUd5Gv7yDQ3mbOUwuy30oSk0z1Q5UUPpoihOugIZHFX6Jk7NLiW2wlqfq9qhV4zj7TiBiJY0mCc4zHN8/aq2VKDHp2Na7mWzvKyTy+SYQkBQ/08LbPwj9YMc+uCzKL6sU/ObHv17EFhD8aPDftTHZvV9L+OZr ;{id = 7698 (ksk), size = 2048b} gov. 3600 IN DNSKEY 256 3 8 AQPUPnOmrICUKGXz/F17uwcAUDaOpSzXtYyVppfFKLCstRguG7MniUDQ7/T5kf+tV7EPcVXca4iJc5WPhKQxCW7O0mSVElgJTbZTgOPpl5TCDYNRLdas7XzJsxadv2FIdQeVopD3tlxgsiB3M1epVEyCS9SxPhEgStLb1A/CnkCYNw== ;{id = 51929 (zsk), size = 1024b} gov. 3600 IN DNSKEY 256 3 8 AQPXzCGIOpznwWOcAVVA4J0lUvtY+K9sEETwbUl8uoh4tmREv2PkfBFID3aL5Nyl3MUrCN6UsP+Tvu+Yj6pi7DEBhOHMxItwocix9cu9VxstQMQ2U2NYs1unUD77W5PmN/000hA4lQS/JrD89XfrmRv2zHPRzw5AsdrfVLm1K0rb+w== ;{id = 46733 (zsk), size = 1024b} sigs: gov. 3596 IN RRSIG DNSKEY 8 1 86400 20140128224731 20140113224231 7698 gov. UdHmEpD0jhpyM5QSI4Te4XYIoPYZiLLN2TvYt56rXDTrmClHNb2WfI5XyDzqAMhOlGvGF9vvkxCK+rxle3OTbKKKWzVzPhxQKDXCAB5ixvR5Mhu7yiH2T4W9FNo7EpyNQ3iI6y3/1SuoExhtgmC2fi0ajF2PkQgj6t+2G1bHJrcMxA9dbwf6ZSZF8JBTdVrW0rjSduAAccQ8URwZx54cF4aMI6idrq0XnFAcnIhw8oGu0EesKCgE3GAuMBtPRINMIFaEAqGGh5g07gOn2gu4I/JFRh5Ni2XCyG08FwbgL8sbTF0qJGr4wpWnzkr42dSQCmk/k0GabzYwAIPt0JNJnQ== --- ;; rcode: NOERROR ;; qtype: DS rrset: fbi.gov. 3600 IN DS 60816 7 2 dafec16d6066c3b7086e27015061674570572819b3d9c79aeb4cd9d8f44889f6 fbi.gov. 3600 IN DS 24840 7 1 1a587e6ffaf669448d6cef00403e3b91a9b33916 fbi.gov. 3600 IN DS 24840 7 2 0c31ebaed7f6a22619eadd082417ab38fa4b4af871fd6507f040cd916b098d18 fbi.gov. 3600 IN DS 60816 7 1 938e49efccdd177417b0c252c8c706b3108f6f79 sigs: fbi.gov. 3600 IN RRSIG DS 8 2 3600 20140127160024 20140120160024 51929 gov. AABChEniI48Iiy5j47ZzUSiflNt8ksxJITw6xK021GKhm+qAfewtP/g50FDPFFw/ys51s9UNYmSRgS/Yx0qCX8TMZ7R/0mg3zlLeVm+iJIUdhaEHNLu8ZWYotmkDv6yM8lmNiMFVBQF30XVeXcni8eOFxu6d/+XCyWiNAi9dGFw= --- ;; rcode: NOERROR ;; qtype: DNSKEY rrset: fbi.gov. 600 IN DNSKEY 256 3 7 BQEAAAAB17UX5M/RKhkRgfUM4GYr+wCTTfLpe232895mX0GH/3R2SnYFTTCEPF7hNF5nkt6yW57fs1wt8/FrdQom7lRLZhgaZdXHGNSbLraq8jMAq9CmNvoNzhoiXbOUdwf2Hw2zcrozYgAoEfxeX0cCf5je4DSRkwEHZ7L+t2y15M9WwZk= ;{id = 58969 (zsk), size = 1024b} fbi.gov. 600 IN DNSKEY 257 3 7 AwEAAcbqigwPaVWRtu5tXoSIHRnjafvgHIKVo/I1nWZpCgCgGEwy6AZ4+OxktFgaVtVEIqNyeeCM9pkjly1isnwZDcWRHbzwmJ3dgKfnml8c5GIJnPp+4NcUHh8YzV+NAurNxaOWp7VDgJRuUejkyKNStia8B4WgcHK26ztGjy6wA/lkVUmea0H/EawqxrolACAD44kYjSpHxTx2dLeoqLfA4BR38aVCT8QTR6jb0Prt2x3v5bGxsW8nv9EvYZOYJHxzhZ6qoPKTCSFpXbPJvJRe/OQpIM+oANQzqPJtnnXNQqa72bJz4xZ4ybZo5tDbqEbY9i/i1KfZxxin01tz1Sk8o8M= ;{id = 24840 (ksk), size = 2048b} fbi.gov. 600 IN DNSKEY 257 3 7 AwEAAco9GtgN9u27gk77N3mrGDJ/ifCuPjJVba6bNnEqcamqf/Zhz5ysspP2LuQN2Grn1neWPLNZxi/fIzQDw+r3fUw8++W28AXt4nH+7J3vmySBX+kEwCXuzhigxXWHnh6TawVDmKFHAh/VOqFjXVRvOBW18S4PJ+ee+AwOtQh60tNuPNBVQvNkuOrG6q1o1OnLYyP9dKkcEK7FwH6lo11qNhwq8z6VFgQV7Kc1RxPiKEI/22GCFlzzyqTdN3DGbwiwIMcgVeJWvOBhQRRjoF/VPZ0eEDqQAG8mFamTcz7YU7J0fmhRKnJxEnr/dNcDYgibDOpW/ZIDiDD2JX9BzJgPV/U= ;{id = 60816 (ksk), size = 2048b} fbi.gov. 600 IN DNSKEY 256 3 7 BQEAAAABo4psWp89WZYhcyU1e7HiJgURDcNSPRJigtcKjUZq+zm3smS++eQyjVDZQOWsQxyyCw/HF1sT/goY2VO7Nm6uQ7y/kxgGeTkTiQAkcJ9GEI30RHaWrdMlmFuMLHV0Hdf9OxuXqAxLdEjq4UcVz0C/L5y6KECIlrFwFA/PPsdbpZc= ;{id = 32497 (zsk), size = 1024b} sigs: fbi.gov. 593 IN RRSIG DNSKEY 7 2 600 20140205145352 20131107145352 24840 fbi.gov. lA986MS27bBKnX7eh7SltOHR9v/mtsHoQeIXzzfImghvfbZcl920RUVZk0byZOcIYq4xezY5eW4uHaBFQ+Ii2JypVhLT3kUks/PKRe1R3S+2Q9XMMTV3ArUtQfTwRvpSFCTJEoyWTE3bOQkbQdWjznyI6wyRARg/QS+v4J/2peVIsOAT5Zu9BbcpUkVVyxKA2uj72AAoH9la15oub1k9/2pUCKlZz+qNTVrJp2U0lV8tUij0YHE0gzoR3rYVQHmDd2xuGFPQj2oX9/im4LVsI1nyliXVKFSNht8CSGTKD5q7Q8rTaprQpptCDdmX1dqlv/hhycNNU66x7PiQEd2euQ== fbi.gov. 593 IN RRSIG DNSKEY 7 2 600 20140205145352 20131107145352 32497 fbi.gov. FQmiZhw87K7RueZ9Bdu/MKn7A/SxCSUPEm3p+cAuK9ATbydaChgVF5YlWCceaVC0l8NRyePmKHouBMy9JocJh5sZkIZsFu0RRLezgd0h0UkMtyhvfivK7eIhFTbMrGgFnPUiS9JsFcBTQYb8KR6bhvIrSFv86CiuGhr96dzpX4g= --- ;; rcode: NOERROR rrset: www.fbi.gov. 598 IN CNAME www.fbi.gov.c.footprint6.net. sigs: www.fbi.gov. 598 IN RRSIG CNAME 7 3 600 20140205145352 20131107145352 32497 fbi.gov. WYmt4GrH4X8PLndOgSLy12MPlWzv85dS7HnSsIMCcqm54Ub66V1Bp/KgtFthUWNf7IMTAnk/X8cT2TXzffJ41I0SXXFdUlhi9WrQlUPTWzwbkKFxGICzzD6jpWPdXBJe/FMecSGwCFCdEPaL+9B5ZewzJk1XxQLlfE86hNQ7gKE= --- Trust tree: www.fbi.gov. (CNAME) |---fbi.gov. (DNSKEY keytag: 32497 alg: 7 flags: 256) |---fbi.gov. (DNSKEY keytag: 24840 alg: 7 flags: 257) |---fbi.gov. (DS keytag: 60816 digest type: 2) | |---gov. (DNSKEY keytag: 51929 alg: 8 flags: 256) | |---gov. (DNSKEY keytag: 7698 alg: 8 flags: 257) | |---gov. (DS keytag: 7698 digest type: 2) | | |---. (DNSKEY keytag: 33655 alg: 8 flags: 256) | | |---. (DNSKEY keytag: 19036 alg: 8 flags: 257) | |---gov. (DS keytag: 7698 digest type: 1) | |---. (DNSKEY keytag: 33655 alg: 8 flags: 256) | |---. (DNSKEY keytag: 19036 alg: 8 flags: 257) |---fbi.gov. (DS keytag: 24840 digest type: 1) | |---gov. (DNSKEY keytag: 51929 alg: 8 flags: 256) | |---gov. (DNSKEY keytag: 7698 alg: 8 flags: 257) | |---gov. (DS keytag: 7698 digest type: 2) | | |---. (DNSKEY keytag: 33655 alg: 8 flags: 256) | | |---. (DNSKEY keytag: 19036 alg: 8 flags: 257) | |---gov. (DS keytag: 7698 digest type: 1) | |---. (DNSKEY keytag: 33655 alg: 8 flags: 256) | |---. (DNSKEY keytag: 19036 alg: 8 flags: 257) |---fbi.gov. (DS keytag: 24840 digest type: 2) | |---gov. (DNSKEY keytag: 51929 alg: 8 flags: 256) | |---gov. (DNSKEY keytag: 7698 alg: 8 flags: 257) | |---gov. (DS keytag: 7698 digest type: 2) | | |---. (DNSKEY keytag: 33655 alg: 8 flags: 256) | | |---. (DNSKEY keytag: 19036 alg: 8 flags: 257) | |---gov. (DS keytag: 7698 digest type: 1) | |---. (DNSKEY keytag: 33655 alg: 8 flags: 256) | |---. (DNSKEY keytag: 19036 alg: 8 flags: 257) |---fbi.gov. (DS keytag: 60816 digest type: 1) |---gov. (DNSKEY keytag: 51929 alg: 8 flags: 256) |---gov. (DNSKEY keytag: 7698 alg: 8 flags: 257) |---gov. (DS keytag: 7698 digest type: 2) | |---. (DNSKEY keytag: 33655 alg: 8 flags: 256) | |---. (DNSKEY keytag: 19036 alg: 8 flags: 257) |---gov. (DS keytag: 7698 digest type: 1) |---. (DNSKEY keytag: 33655 alg: 8 flags: 256) |---. (DNSKEY keytag: 19036 alg: 8 flags: 257) ``` ## Voice Utilities ### te-rtp Designed to initiate an instant voice call to a VoIP server. It includes options to choose different Differentiated Services Code Point (DSCP) and codec values. Voice packets are encapsulated by a Real Time Transport Protocol (RTP) header, followed by further encapsulation through the transport layer protocol UDP and then sent using IP #### Syntax and Options (sudo) te-rtp \[options] \ | **Parameter** | **Description** | | ------------- | ------------------------------ | | target-ip | IP address of the VoIP server. | | **Option (short)** | **Option (long)** | **Description** | **Default Value** | | ------------------ | ----------------- | ------------------------------------------------------------------------------------------------------------- | ----------------- | | -h | --help | displays usage instructions | n/a | | | --source-port | source port to be used for the test | \ | | -p | --port | destination port for the probe | 5000 | | -P | --paths | # of paths to trace (in parallel) | 1 | | -i | --interface | interface name to use for the test (use in conjunction with --source-ip option) | any | | -s | --source-ip | source IP address ( use in conjunction with --interface option) | n/a | | | --dscp | DSCP value to be used for the voice call | 0 = best effort | | | --codec | Audio codec value used for the VoIP call, 0=G.711, 1=G.722\_24, 2=G.722\_32 | 0 = G.711 | | -d | --stream-duration | To run the voice test call for desired time in seconds. For each 5 seconds, 50 packets are sent to the server | 5 seconds | | -o | --clock-offset | clock offset with the server | 0 | | -v | --verbose | verbosity of the test; short command accepts -v (verbose) or -vv (very verbose), -vvv (very very verbose) | n/a | ### te-server Designed to open up a port on the local machine to allow communication with the VoIP client. The desired server port should be configured to accept UDP connections inbound. It is always the machine running the te-voipserver utility that logs the probe statistics. #### Syntax and Options (sudo) te-server \[options] \ | **Parameter** | **Description** | | ------------- | --------------------------------------------------------------------------- | | local-port | Port on which the sever listens for incoming VoIP connections (UDP traffic) | | **Option (short)** | **Option (long)** | **Description** | **Default Value** | | ------------------ | ----------------- | --------------------------------------------------------------------------------------------------------- | ----------------- | | -h | --help | displays usage instructions | n/a | | | --stunner-host | host in which to reach the STUNNER server | | | | --stunner-port | port in which to reach the STUNNER server | | | -6 | --ipv6 | use IPv6 instead of IPv4 | n/a | | -j | --jitter | the size of the de-jitter buffer | 0.1000000001 secs | | | --check-nat | whether to check if the NAT allows hole punching (only valid when using --stunner-host) | 1 | | | --agent-id | the agent id to use when connecting and authenticating to the STUNNER server | 0 | | -v | --verbose | verbosity of the test; short command accepts -v (verbose) or -vv (very verbose), -vvv (very very verbose) | n/a | #### Example ``` user@ubuntu:~$ sudo te-server 49152 13 [0x7fab82d4c700] INFO te.pte null - ProbeTaskExecutor started. 65 [0x7fab82d4c700] INFO te.port_49152#1 null - port_49152 server task started. ``` ``` [user1@centos]$ sudo te-rtp 10.100.10.166 -p 49152 241 packets sent in 5000ms @96% of rate ``` ``` user@ubuntu:~$ sudo te-voipserver 49152 13 [0x7fab82d4c700] INFO te.pte null - ProbeTaskExecutor started. Server listening at port 49152 on interface any 65 [0x7fab82d4c700] INFO te.port_49152#1 null - Voip server receiving streams at 0.0.0.0:49152 44435 [0x7fab82d4c700] INFO te.port_49152#1 null - Task/Client 0/0: round #1407879622 (G.711_64kbps): 482/0/0 (total/lost/discarded frames); wall time: 5001 @ 98% of desired rate; MOS: 4.4; OWD: 0.0; jitter(RTCP/PDV): 0.0/0.0; ``` **Note: The wall time accounts for the total time taken for the test to complete including the programmatically added time and/or time taken for the resources to be made available.**
